Product Details
- Size: standard
- Place of Origin: China
- Brand Name: XinQiang Machinery
- Model Number: DZS
- Weight: 2000.000 kg
Product Description
It is widely used in industries like mine, coal smelt, construction, refractory marerial, light industry, and chemical industry.
Feature
1, Small amplitude, high frequency, large-inclination structure, high efficiency, large capacity, long service life, low power consumption and noise.
2, Fully enclosed structure, automatic layout, more suitable for assembly line operations.
| model | screen area（㎡） | amplitude（mm） | model of motor | power of motor（kw） | rotating speed(r/min) |
| DZS0410 | 0.4*1.0 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0412 | 0.4*1.2 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0415 | 0.4*1.5 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0612 | 0.6*1.2 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0718 | 0.7*1.8 | 3-5 | YZ0-20-8 | 1.0 | 730 |
| DZS0816 | 0.8*1.6 | 3-5 | YZ-10-6 | 1.0 | 950 |
| DZS0918 | 0.9*1.8 | 3-5 | YZ0-20-6 | 2.0 | 950 |
| DZS1018 | 1.0*1.8 | 3-5 | YZ2-20-6 | 2.0 | 950 |
| DZS1020 | 1.0*2.0 | 3-5 | YZ0-20-6 | 2.0 | 950 |
| DZS1225 | 1.25*2.5 | 3-5 | YZ0-20-6 | 2.0 | 950 |
| DZS1530 | 1.5*3.0 | 3-5 | ZDS41-6 | 3.0 | 940 |
- Size: standard
- Place of Origin: China
- Brand Name: XinQiang Machinery
- Model Number: DZS
- Weight: 2000.000 kg
| model | screen area（㎡） | amplitude（mm） | model of motor | power of motor（kw） | rotating speed(r/min) |
| DZS0410 | 0.4*1.0 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0412 | 0.4*1.2 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0415 | 0.4*1.5 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0612 | 0.6*1.2 | 3-5 | ZDS21-6 | 0.4 | 930 |
| DZS0718 | 0.7*1.8 | 3-5 | YZ0-20-8 | 1.0 | 730 |
| DZS0816 | 0.8*1.6 | 3-5 | YZ0-10-6 | 1.0 | 950 |
| DZS0918 | 0.9*1.8 | 3-5 | YZ0-20-6 | 2.0 | 950 |
| DZS1018 | 1.0*1.8 | 3-5 | YZ0-20-6 | 2.0 | 950 |
| DZS1020 | 1.0*2.0 | 3-5 | YZ0-20-6 | 2.0 | 950 |
| DZS1225 | 1.25*2.5 | 3-5 | YZ0-20-6 | 2.0 | 950 |
| DZS1530 | 1.5*3.0 | 3-5 | ZDS41-6 | 3.0 | 940 |
